The Masters of Battery Management
Giving You The Power You Need
Merlin’s Battery Management Controllers can be likened to an in-vehicle engine management computer. Instead of controlling fuel flow and RPMs, Merlin’s controllers manage every function in your primary electrical system.
Functions such as remote battery switching, charge prioritization, intelligent split charging, flat battery protection, alarms, and automation of load shedding (non-essential loads) and generator stop/start are all controlled through the Merlin Battery Management system.
How does management control differ from battery monitoring? Put simply, Merlin’s Battery Monitors detect weaknesses, power discharge, and overloads in the electrical system. Merlin’s Battery Management Controllers use the data to correct these problems automatically – before your batteries fail.
Proactive. Safe. Both monitoring and management are vital to the reliable operation of your vehicle or boat.
Configuration Management
Each Management Controller is highly configurable. All parameters can be customized, including
expandable inputs and outputs. You can work with our application engineers to design systems that
precisely meet your power management needs.
Our management systems deliver extremely accurate readings of your battery bank’s State of Health
(SoH) and State of Charge (SoC). Protecting primary and back-up batteries from overload and overuse,
Merlin Battery Management Controllers automatically direct power where it is needed most.
Battery Management Solutions Include:
SmartGuard COMBI
Available For 12 And 24V Electrical Systems
Remote battery switching for two battery
banks
Dead battery protection for two battery
banks
8x inputs/outputs related to split charging
Interlocks such as Ignition Inhibit,
external alarms, and automatic or manual
control (e.g., load shedding and generator
stop/start)
Split charging for two battery banks
Emergency parallel and jump-start
8x inputs/outputs related to battery
switching and dead battery protection
IP66 sealed, ignition-protected contactors
Power Bank
Remote battery switching for up to 4
battery banks
Multiple alarms for high and low voltage
or state of charge
Flat battery protection for up to 4 battery
banks
MerlinNET connectivity allows easy
system customization
Split charging for up to 4 battery banks
MerlinNET Expansion Module adds 16x
input/outputs
PowerBank COMBI Kit
Combines both PowerBank and DataCell
battery monitoring and power
management into a single compact unit
Includes MerlinNET cables
Programming and DataLogging Kit
included
Suitable for 12V and 24V systems up to 4
battery banks
The only extra items needed are
contactors and any required expansion
modules
Includes LED or LCD remote panel
MerlinNET
MerlinNET is a proprietary high-speed, databus that allows enabled devices to share data.
With MerlinNET, you can easily expand your system, both monitoring and managing your batteries at multiple stations on board.
For example, on boats, battery control and monitoring may be required at the helm, in the engine compartment, and in the saloon. In vehicles, you may require full monitoring and control on the dashboard, but only indicators and audible alarms at the rear. MerlinNET makes configuration flexible.
MerlinNET is also a full duplex, deterministic network with automatic device addressing and configuration. You can simply plug in new or replacement modules. Because no programming or configuration is necessary, MerlinNET makes in-field replacement and support easy. MerlinNET-enabled devices currently include: PowerBank, PowerBank COMBI, Expansion Module, PowerBank Remote Panel, and DataCell.
